High-quality straddle carrier crane for sale from Nybon Machinery. 15-50 Ton capacity, straddle design for steel plates, pipes & containers. Customizable, free quote!
Our straddle carrier crane is versatile and adaptable, making it suitable for a wide range of industries and applications where heavy, bulky loads need to be lifted and moved. Some of the most common uses include:
Below is the standard technical parameter table for our straddle carrier crane. All specifications can be fully customized to meet your specific project requirements, including load capacity, leg span, lifting height, power supply, control system, and movement type (rubber-tyred or rail-mounted). Contact our team to discuss your needs and receive a tailored solution.
| Parameter | Standard Specification | Customizable Range |
|---|---|---|
| Load Capacity | 15-50 Ton | 10-60 Ton |
| Leg Span | 8-20 Meters | 6-25 Meters |
| Lifting Height | 6-15 Meters | 5-20 Meters |
| Lifting Speed | 2-8 m/min | 1-10 m/min (Variable Speed Optional) |
| Travelling Speed | 15-30 m/min | 10-40 m/min (VFD-Controlled Optional) |
| Working Class | A5-A6 (FEM/ISO Standard) | A4-A7 |
| Power Supply | Diesel + Electric (Dual Power) | Full Electric / Hybrid Power (Custom) |
| Control System | Pendant Control / Wireless Remote Control | Cabin Control / Dual Control (Optional) |
| Operating Environment | -20°C to +60°C, IP55 Protection | High Temperature/Corrosion-Resistant (Custom) |
| Movement Type | Rubber-Tyred (Standard) | Rail-Mounted / Rubber-Tyred (Custom) |
Since its inception, Nybon Machinery has focused on the manufacturing of heavy lifting equipment.
Our main products include bridge cranes, gantry cranes, rubber tyred gantry cranes, rail-mounted container gantry cranes, straddle carriers, transporters, as well as casting cranes, hoists and beam launching machines.
We stand out with our strong design and customization capability, offering tailored solutions to meet customers’ unique needs.
Customization Service
At Nybon Machinery, we recognize that every heavy-duty lifting project has unique requirements. That’s why we offer fully customizable double girder gantry crane solutions to fit your specific needs. Our team of experienced engineers will work closely with you to tailor every aspect of the crane, including load capacity, span, lifting height, control system, structural design (such as cantilever length, leg type, and track configuration), and special features. Whether you need a crane for high-temperature steel mill operations, corrosive port environments, or precision heavy lifting, we can design a solution that meets your exact specifications. Optional features include anti-sway systems, laser-guided positioning, remote monitoring, and special coatings for harsh conditions. Contact us today to discuss your customization needs and get a free design proposal.
A: The key difference lies in the design and mobility. A straddle carrier crane has a unique straddle leg design that allows it to surround and lift loads from the side, while standard gantry cranes typically lift loads from above. Additionally, straddle carrier cranes are often mobile (rubber-tyred or rail-mounted), allowing for free movement across yards, whereas many standard gantry cranes are fixed or require fixed tracks. This makes straddle carriers ideal for moving bulky loads across open areas without fixed infrastructure.
A: Yes, our straddle carrier crane is designed to handle irregularly shaped and bulky loads, such as steel plates, pipes, and precast components. The adjustable leg width and flexible hoist system allow the crane to accommodate different load sizes and shapes, while the stable straddle design ensures safe lifting and transport. We can also customize the lifting attachments (such as spreader bars or clamps) to suit specific load types.
A: Our straddle carrier cranes come standard with a dual power system (diesel + electric), which combines the mobility of diesel power for travel with the efficiency of electric power for lifting operations. We also offer customizable power options, including full electric (for facilities with a reliable power grid) and hybrid power (for improved fuel efficiency and reduced emissions). The power system can be tailored to your operational needs and environmental requirements.
A: The manufacturing time for a standard straddle carrier crane (15-50 tons, standard configurations) is 4-6 weeks. Customized cranes, especially those with special power systems or attachments, may take 6-8 weeks to manufacture. Installation typically takes 5-7 days, depending on the crane’s size, complexity, and site conditions. We work with trusted logistics and installation partners to ensure timely delivery and setup worldwide. Contact us for a specific timeline based on your order.
A: Yes, we offer full turnkey solutions, including professional installation by our team of experienced technicians. Our team will travel to your site to assemble, test, and commission the crane, ensuring it meets all safety and performance standards. We also provide comprehensive after-sales service, including regular maintenance, repairs, spare parts supply, and 24/7 technical support. Our goal is to ensure your straddle carrier crane operates smoothly and efficiently, minimizing downtime and maximizing productivity.
A: Yes, our straddle carrier cranes are designed for outdoor use in harsh weather conditions. The steel structure is treated with anti-corrosion coatings to resist rain, wind, and rust, while the electrical components have IP55 protection to prevent damage from humidity and extreme temperatures (-20°C to +60°C). The rubber tires (for mobile models) are heavy-duty and designed to withstand rough terrain and inclement weather, ensuring reliable operation year-round.
Contact Nybon Machinery today via email or phone to discuss your single girder gantry crane needs, get a free quote, or learn more about our products and services. We look forward to helping you find the perfect lifting solution for your business!
When you choose Nybon Machinery for your single girder gantry crane, you’re partnering with a trusted manufacturer with years of experience in the heavy machinery industry. Here’s why our clients around the world choose us:
