High-quality single girder gantry crane for sale from Nybon Machinery. Lightweight, easy to install, cost-effective for workshops, yards & construction sites. 1-20 Ton, customizable. Free quote!
Our single girder gantry crane is versatile and adaptable, suitable for a wide range of industries and applications. Its light to medium-duty capacity and flexible design make it ideal for the following scenarios:
Below is the standard technical parameter table for our single girder gantry crane. All specifications can be fully customized to meet your specific project requirements, including load capacity, span, lifting height, power supply, control system, and structural design. Contact us to discuss your needs and get a tailored solution.
| Parameter | Standard Specification | Customizable Range |
|---|---|---|
| Load Capacity | 1-20 Ton | 0.5-30 Ton |
| Span | 5-30 Meters | 3-35 Meters |
| Lifting Height | 6-20 Meters | 3-30 Meters |
| Lifting Speed | 3.2-16 m/min | 1-20 m/min (Variable Speed Optional) |
| Travelling Speed | 20-40 m/min | 10-60 m/min (VFD-Controlled Optional) |
| Working Class | A3-A5 (FEM/ISO Standard) | A1-A5 |
| Power Supply | 380V/50Hz/3Phase | 220V-480V, 50/60Hz (Regional Standards) |
| Control System | Pendant Control / Wireless Remote Control | Cabin Control / PLC Control (Optional) |
| Operating Environment | -20°C to +50°C, IP55 Protection | High Temperature/Corrosion-Resistant (Custom) |
| Hoist Type | Electric Wire Rope Hoist / Chain Hoist | Custom Hoist Type Based on Needs |
Since its inception, Nybon Machinery has focused on the manufacturing of heavy lifting equipment.
Our main products include bridge cranes, gantry cranes, rubber tyred gantry cranes, rail-mounted container gantry cranes, straddle carriers, transporters, as well as casting cranes, hoists and beam launching machines.
We stand out with our strong design and customization capability, offering tailored solutions to meet customers’ unique needs.
Customization Service
At Nybon Machinery, we understand that every project has unique requirements. That’s why we offer fully customizable single girder gantry crane solutions to meet your specific needs. Our engineering team will work closely with you to tailor the crane’s specifications, including load capacity, span, lifting height, control system, and structural design (such as cantilever length, leg type, and coating). Whether you need a crane for a narrow workshop, a harsh outdoor environment, or a specialized lifting task, we can design a solution that fits your exact requirements. We also offer optional features like anti-sway systems, laser-guided positioning, and special corrosion-resistant coatings for coastal or industrial areas. Contact us today to discuss your customization needs and get a free design proposal.
A: The main difference is the number of girders (horizontal beams). A single girder gantry crane has one beam, making it lightweight, compact, and cost-effective—ideal for light to medium-duty loads (1-20 tons). A double girder gantry crane has two beams, offering higher load capacity (10-200 tons), greater stability, and longer spans, but it is more expensive and requires more space. Single girder cranes are perfect for small businesses or projects with limited budgets, while double girder cranes are suited for heavy-duty industrial applications.
A: Yes, our single girder gantry cranes are designed for both indoor and outdoor use. The steel structure is treated with anti-corrosion coatings (hot-dip galvanization or epoxy) to resist rain, wind, and rust, while the electrical components have IP55 protection to ensure reliable operation in harsh weather conditions. We also offer optional wind-resistant features for areas with strong winds (up to 20 m/s).
A: Standard single girder gantry cranes (1-20 tons, standard specifications) can be manufactured in 2-4 weeks. Installation typically takes 3-5 days, depending on the crane’s size and the site conditions. Customized cranes may take slightly longer (4-6 weeks for manufacturing) based on the complexity of the design. We work with reliable logistics partners to ensure timely delivery and installation worldwide. Contact us for a specific timeline based on your order.
A: Yes, we offer full turnkey solutions, including professional installation by our experienced technical team. Our team will travel to your site to assemble and test the crane, ensuring it meets all safety and performance standards. We also provide comprehensive after-sales service, including maintenance, repairs, spare parts supply, and technical support. Our team is available 24/7 to address any issues or questions, ensuring your crane operates smoothly for years to come.
A: Our single girder gantry cranes are manufactured in compliance with international standards, including ISO 9001, CE, and FEM. We conduct strict quality control tests throughout the manufacturing process—from material selection to final assembly—to ensure safety, reliability, and performance. All our cranes come with complete certification documents to meet the requirements of global markets.
A: Yes, we offer three main control methods to suit your needs: pendant control (ideal for close-range operation), wireless remote control (for flexible, long-distance operation), and cabin control (for operators who need a clear view of the lifting area). We can also provide dual control systems (e.g., pendant + remote control) for added convenience. The control system is user-friendly and easy to operate, with clear buttons and intuitive controls.
Contact Nybon Machinery today via email or phone to discuss your single girder gantry crane needs, get a free quote, or learn more about our products and services. We look forward to helping you find the perfect lifting solution for your business!
When you choose Nybon Machinery for your single girder gantry crane, you’re partnering with a trusted manufacturer with years of experience in the heavy machinery industry. Here’s why our clients around the world choose us:
Tell us your requirements and our engineering team will provide a tailored lifting solution with competitive pricing within 24 hours.
From design to delivery, we ensure reliable, efficient, and cost-effective crane systems for your business needs. Whether you need a gantry crane, overhead crane, or complete lifting solution we are here to help.
